SOL 49 END-OF-DAY DOWNLINK STATUS REPORT

Last updated: 23 Aug 1997, 05:45 PDT, Data Controller: Allen R. Sirota

Summary Report
Retransmit Requests
Sequence Planning Recommendations & Constraints
Sequence Execution Status
Telemetry Volume
Traverse Hazards (Detected)
Subsystem Reports
Telemetry Processing Anomalies
Press Release


Shark with barcode label



SUMMARY REPORT

Retransmit Status:

Sequence 54710B: Sequence 54910B:


RETRANSMIT REQUESTS




SEQUENCE PLANNING RECOMMENDATIONS

Modify sequence for Sol 51

Operational Constraints (for Sol 51 Sequence):

  1. New or changed recommendations:
    • None

Engineering Requests:
  1. HAVE S0050 IMAGES TAKEN DURING WAYPOINT COMMANDS ... ESPECIALLY WHEN DRIVING OVER ROUGH TERRAIN!
  2. S0050 images at Low-Compression (3:1).
  3. (DESIRE) Take rover images as early in the morning as possible to reduce dark noise current.
  4. (DESIRE) Leave rover on until 15:45 LST to collect late afternoon thermal data, perform health check just before shutdown.
  5. (DESIRE) Perform Wheelie before start of Traverse and Soil Experiment at end of Sol's traverse when practical
Operational Constraints (General):
  1. Make sure sequence has as many days of runout as possible (analogous to the design of the 54710B sequence.
  2. Perform EOD Synch Clock AFTER Clear Errors so it is not skipped.
  3. Change morning wakeup time (via night shutdown) to 8:00 LTST.
  4. Accelerometers
    • DISABLE the Y accelerometer during moves and waypoints at risk level 1
    • CAN DISABLE the Y accelerometer during moves at risk level 2 ONLY IF planned path appears 'safe'; otherwise ENABLE Y accelerometer.
    • ALWAYS ENABLE Y accel for waypoints at risk level 2
    • Leave X accelerometer ENABLED
    • Leave Z accelerometer DISABLED
  5. Heating
    • Set modem Heat and Reheat parameters both to "0" prior to shutting down for the night if LMRE is NOT going to be turned on prior to expected rover solar wakeup of ~7:15 LST. Reset them back to normal values on the morning of "runout" Sols. Disable battery usage for modem heating on runout mornings.
    • Set Modem Heat to 15 minutes; 10 minutes if following a night-time APXS
    • Set Modem Reheat to 5 minutes and maximum modem reheat temperature 30 deg
    • Enable Modem Heat and Reheat only when LMRE is ON.
    • Perform WEB heating on days of low activity (i.e. no traverses) with no night-time APXS operations and Runouts.
    • Use Web_Heat_B parameter with Max temp of +30C from 13:00 to 15:00 when WEB heating.
    • Set Web_Heat_B parameter to -30C (-273) when not heating.
    • Always leave Web_Heat_A parameter at +40C (1197).
    • Limit image transfer after 1:00 LST (to prevent overheating)
  6. Traverses
    • Do NOT move with Bogie potentiometers disabled.
    • Enable hazard avoidance using sensors, contacts, and laser proximity, and perform each waypoint command only once.
    • Limit each "Move Command" distance to 0.5 meter or less to enable gyro to be recalibrated and thereby reduce the amount of drift.
    • Before beginning traverses, should back up a little (~ 10 cm) to enable lasers to detect hazards which may be very close to the front of the rover. UNMASK contact sensors for this move. May want to then move forward ~ 1 cm, with contact sensors MASKED to remove any contact that may have been made during the previous backward move. Then UNMASK all contact sensors and plan subsequent waypoints.
    • When performing long waypoint traverses with "thread-the-needle" enabled like that performed on Sol 35, break the waypoints up such that the last segment is performed with "thread-the-needle" disabled. This way the vehicle will make sure (most likely) that it ends up in a location in which it can safely turn in place without climbing on nearby obstacles. If the vehicle stops because it can not find a path as wide as the turn circle, subsequent turn commands will be skipped ... and we may be able to avoid the situation we ran into on Sol 36.
  7. Health Checks
    • If need to perform Level 3 health checks between Sol n, 20:00 LST and Sol n+1,8:00 LST, disable lasers (i.e., never power) to prevent them from being turned on. Re-enable afterwards.
    • Always command a Level 2 Health Check before shutdown.
    • Perform level 2 health check at the end of every traverse command
    • If possible, health checks should not be skipped as a result of traversable hazards.
  8. Mask all errors (except INVALID CMD) immediately prior to "Read Mem" of persistent state table. Unmask accordingly immediately afterwards.
  9. Perform Read Memory just before last downlink session
  10. Perform Sync Clock just prior to EOD shudown (or LMRE off) after Clear Errors.
  11. Disable auto shutdown
  12. DISABLE RF Wheel Temperature Sensor
  13. Insert longer wait (10 seconds) between APXS cycle start command and APXS turn-off command (turn off devices) .
  14. Future soil mechanics experiments in suspected hard material should have 6 spins of 500 counts rather than 4.


SEQUENCE EXECUTION STATUS & VEHICLE STATE

SEQUENCE EXECUTION STATUS (AS OF EOD SOL 49):

VEHICLE STATE(AS OF EOD SOL 49): (AS OF COMMAND: 0 (Auto Health Check after command 49101)
SCET: 8/23/97 11:36, MLST: Sol 49 13:48 )

BATTERY STATE/USAGE(AS OF EOD SOL 49 .. NOT Sol 50) - Covers Sols 45-49

SUBSYSTEM STATUS (AS OF EOD SOL 49):



TRAVERSE HAZARDS (DETECTED)



TELEMETRY VOLUME



SUBSYSTEM REPORTS

NAVIGATION PERFORMANCE:

THERMAL PERFORMANCE:

TELECOM PERFORMANCE

MOBILITY PERFORMANCE:

POWER PERFORMANCE:



TELEMETRY PROCESSING ANOMALIES


PRESS RELEASE

TBD
